5
Insert the batteries. Refer to the battery
orientation diagram on the side of the detector
to ensure that the batteries are inserted
correctly.
Close the battery door and twist the knob
clockwise as shown.
WARNING:
The waterproof seal on the battery door
must be free of contamination prior to
submerging the detector.
Always clean the seal and its mating
surface and check for damage prior to
underwater use, otherwise serious damage
can be caused to your detector.
Inserting Batteries
The SDC 2300 comes standard with a Lithium-
Ion battery. Insert the battery with the arrows
pointing towards the detector and the battery
charge socket facing outwards. Close the latch
to secure the battery.
The Lithium-Ion battery cannot be charged
while inserted in the SDC 2300 battery
compartment.
Four alkaline C cell batteries can be used to
power the SDC 2300. Only use high quality
alkaline or rechargeable batteries. Minelab
recommends that only rechargeable batteries
with a capacity of 4000 mAh or greater be
used. Rechargeable batteries have specific
charge/discharge maintenance requirements,
which should be strictly followed to ensure
maximum battery life.
Tips:
• Always ensure that your rechargeable
batteries are at full charge.
• Only use high quality batteries.
The battery compartment is located at the
rear of the detector. To open the compartment,
twist the knob in a counter-clockwise direction,
and then pull the door back as shown.
Batteries
