Minelab SDC 2300 User Manual

4
7. Adjust coil angle
Adjust the angle of the coil so that it is parallel
to the ground when the detector is held in the
operational position.
Packing Up
To pack up the detector and return it to its
compact state, perform the following steps:
1. Retract the armrest wings and the armrest.
2. Release the handle snap lever at the base of
the handle and pull backwards on the handle
to collapse.
3. Retract the shafts using the cam-locks
and rotate the shaft and coil back into the
compact position.
Setting Up
Continued…

Minelab SDC 2300 Specifications

General

Type	Gold Detector
Collapsible	Yes
Target ID	No
Ground Balance	Automatic
Technology	Pulse Induction
Waterproof	Yes, up to 3 meters
Coil Size	8-inch round
Audio Output	Internal speaker or headphones
Length Extended	1500 mm
Display	No
Battery Life	Up to 8 hours
Coil Type	Monoloop
