Minelab VANQUISH 340 User Manual

4
CONTENTS
Controls
1. Power On/Off
Turns the detector on and off�
Press and hold from Off (7 seconds) to restore factory settings (page 14)�
2. Volume Adjust
Adjusts the audio Volume Level (page 6)�
3. Sensitivity
Adjusts the Sensitivity Level (page 6)�
4. Search Mode
Selects the next available Search Mode (page 3)�
5. Target Identification Guide
A reference guide indicating the types of targets that can be found for the corresponding
Target Identification Segment�
1
2
3
4
5

Minelab VANQUISH 340 Specifications

General

Technology	Multi-IQ
Waterproof Coil	Yes
Audio Output	Built-in speaker and 3.5mm headphone jack
Search Modes	3 (Coin, Jewelry, All Metal)
Discrimination Segments	5
Target ID	-9 to 40
Display	LCD
Audio Tones	3
Sensitivity Adjustment	4 levels
Ground Balance	Automatic
Weight	1.2 kg (2.6 lbs)
Battery Type	4 x AA
Operating Frequency	Multi-IQ
Length	1450 mm (57")
Battery Life	Approx. 10 hours
