24
EXAMPLE DETECTIONS
Discrimination Pattern
The factory preset pattern 1 rejects ferrous
metals and foil, and accepts nonferrous metals.
Patterns can be edited and saved according to
detecting preferences.
Audio
A detected nonferrous target will give a
medium – high tone audio response.
Visual
A detected nonferrous target will give a visual
indication within the nonferrous section of the
discrimination scale and a positive target ID.
A detected target ID segment (indicated
on the diagram by a grey icon) will flash (if
accepted) quickly 3 times to show its position
on the discrimination scale — just like a cursor
on a computer screen. The segment will
continue to flash slowly until another target ID
segment is detected.
4 icons to
indicate the
targets depth
from the coil,
approx. 6‑8”
(15‑20cm)
Nonferrous coin
Medium
High
