41
All Metal
AM indicates that the all metal pattern
has been selected. This pattern has no
discrimination and will allow signals from all
types of metals, both ferrous and nonferrous.
Patterns
Preset discrimination patterns are used to suit
different search preferences. X-TERRA 305 has
2 patterns, X-TERRA 505 has 3 patterns (Preset
Discrimination Patterns, p. 30).
Depth Indicator
The depth indicator is a relative guide to how
deep a target is. The more arrows displayed,
the deeper the target is likely to be.
1 arrow is approx. 0–2” (0–5 cm)
2 = 2–4” (5–10 cm)
3 = 4–6” (10–15 cm)
4 = 6–8” (15–20 cm)
5 = 8–10” (20–25 cm)
*
Shallow target
Deep target
Actual depth will be more
accurate for coins than junk
ferrous targets.
