Minipa ET-2907 - CONTROLS AND INDICATORS; Front Panel Controls and Indicators

55
Fuse
Battery
2. ELECTROMAGNETIC COMPATIBILITY (EMC)
The meter meet EN61326 : 1997+A1 : 1998. See the backside of this
manual’s cover page.
3. CONTROLS AND INDICATORS
3.1 Front Panel
This manual describe the operation of multimeter, with illustrations and
examples.
(1) 4-4/5 digit, 50000 (Primary display) / 5000 (Secondary display)
count LCD display
(2) On screen menu selection push-buttons
(3) Push-buttons for special functions & features
(4) Selector to turn the power ON or OFF and select a function
(5) Input terminal for 10A (20A for 30 sec.) current measurement
function
(6) Input terminal for milli-amps and micro-amps current
measurement function
(7) Common (Ground reference) input terminal for all measurement
functions
(8) Input terminal for all functions EXCEPT current (A, mA, µA)
measurement functions
(9) RS-232 Optical interface
