To measure AC or DC current:
1. Turn off power to the circuit and discharge all high-voltage
capacitors.
2. Insert the black lead into the COM terminal and the red lead into
an input terminal appropriate for the measurement range as the
following table.
hctiwSyratoRtupnIsegnaR
AµAmAµ0.0005,Aµ00.005
AµAmAm00.005,Am000.05
AA000.01,A0000.5
* To avoid blowing the meter’s 440 mA fuse, use the mAµA terminal
only if you are sure the current is less than 400mA.
