MINN KOTA MK212PC Owner's Manual

9) TROUBLESHOOTING
PROBLEM:
RED LED is lit.
SOLUTION:
-Check polarity of leads to battery.
-Check connections to battery and fuses in output cord.
-Check voltage at battery. The bank will not charge a battery below 4 volts or above 16 volts.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
PROBLEM:
RED LED is flashing with steady 25% YELLOW LED.
SOLUTION:
-Check to make sure there are no power loads on the battery
-Check the fluid in the battery and add fluid per battery manufacturer’s specifications.
-If the voltage of the battery does not increase above 10.5 volts after 3 hours, then the bank will shut down and will not charge. The battery should be tested.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
PROBLEM:
RED LED is flashing with steady 50% YELLOW LED.
SOLUTION:
-Check to make sure there are no power loads on the battery
-Check the fluid in the battery and add fluid per battery manufacturer’s specifications.
-If the voltage of the battery does not increase to the absorption voltage in 20 hours, then the bank will shut down and will not charge. The battery should be
tested.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
PROBLEM:
RED LED is flashing with steady 75% YELLOW LED.
SOLUTION:
-The temperature sensor in the output cord is damaged. If the output cord was extended, check to make sure the procedure in the Safety Instructions 4i was
followed.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
PROBLEM:
RED LED is flashing with steady 25% and 50% YELLOW LEDs.
SOLUTION:
-There is a fault within the charger.
-Reset the charger by unplugging the AC cord. Wait for all LEDs to turn off.
-Plug in the AC cord.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
PROBLEM:
Indicator lights will not illuminate.
SOLUTION:
-Check the AC power at the outlet.
-Make sure the GFCI(Ground Fault Circuit Interrupter) for the outlet has not tripped.
-If an extension cord is being used, check the AC power at the end of the extension cord.
-If still not working, call the Minn Kota Service Department at 1-800-227-6433.
Specifications:
Model Part No. System Volts Banks
Output
per Bank
(amps)
Total
Output
(amps)
Input
Cable
Output
Cable Size L x W x H
Weight
(lbs)
Input Current
(120VAC, 60Hz)
MK115PC 1821151 12 1 15 15 18AWG - 6’ 12AWG - 6’ 6-3/4” x 10” x 3-3/4” 5.3 3.5A
MK230PC 1822301 12 / 24 2 15 30 16AWG - 6’ 12AWG - 6’ 9-1/2” x 10” x 3-3/4” 8.8 7A
MK345PC 1823451 12 / 24 / 36 3 15 45 14AWG - 6’ 12AWG - 6’ 13” x 10” x 3-3/4” 12.4 10.5A
MK460PC 1824601 12 / 24 / 36 / 48 4 15 60 12AWG - 6’ 12AWG - 6’ 16” x 10” x 3-3/4” 15.8 14A
9

MINN KOTA MK212PC Specifications

General

Brand	MINN KOTA
Model	MK212PC
Category	Battery Charger
Language	English
