ADvANCED TROUBLESHOOTING
1
a. Refer to the Trim/Stow Reset Procedure in
this manual.
CORRECTIVE ACTION:
NOTICE: To do the Trim/Stow Reset Procedure, the motor
MUST be in the deployed position, with the motor and shaft
assembly vertical and the latch pin in the steering housing
engaged into the aluminum base extrusion catches.
Case 6
CAUSE: The trim module has lost its position count and needs to be reset.
The Ulterra motor does not rotate into the horizontal position when stowing, or the vertical position when deploying, at the appropriate
time. During the stow sequence the motor lower unit should come straight up and begin to rotate into the horizontal position when the
lower unit is about twelve (12) to thirteen (13) inches below the aluminum base extrusion. During the deploy sequence the motor lower
unit should extend about five (5) to six (6) inches out from the steering housing and then begin to rotate into the vertical position.
