NAMES OF PARTS
* This camera is a sophisticated optical instrument. Care should be taken to keep
these surfaces clean. Please read the care and storage instructions in the back of
this manual (p. 90).
Flash (p. 26)
Self-timer lamp (p. 32)
Lens*
Main switch
Microphone
AV-out-terminal/USB-port cover
Viewfinder*
Indicator lamp (p. 87)
Mode switch
Left key
Right key
Zoom lever (p. 21)
LCD monitor*
Display button (p. 52, 56)
Flash-mode/delete button (p. 26, 55)
Menu button
Enter button
Speaker
Recording mode (p. 20)
Tripod socket
Battery/Card chamber door (p. 13, 16)
DC terminal (p. 15)
Strap eyelet (p. 15)
Shutter-release button
Viewfinder window*
Playback mode (p. 54)
(Located on the bottom of
the body.)
