— 15 —
possible. Begin by drilling and tapping four (4) #10
- 24 holes in the control panel to anchor the fuse
holders. Then mount and secure the fuse holders to
the panel.
CAUTION
WHEN DRILLING AND TAPPING HOLES FOR THE
FUSE HOLDER MAKE SURE THAT NO METAL
SHAVINGS FALL ON ANY CIRCUIT BOARDS OR
ANY OTHER ELECTRIC DEVICES.
7. Remove the wire from terminal “Y1” of the trans-
former and re-label it “1Y1.” (NOTE: Re-label both
ends of the wire.) Then attach the wire to the bottom
side of the first fuse.
8. Run a #16 ga. MTW grade wire (or equivalent) from
the top of the first fuse to terminal “Y1” of the 100
Volt transformer. Label this wire “Y1.”
9. Remove the wire from terminal “Y2” of the trans-
former and re-label it “2Y2.” (NOTE: Re-label both
ends of the wire.) Then attach the wire to the bottom
side of the second fuse.
10. Run a #16 ga. MTW grade wire (or equivalent)
from the top of the second fuse to terminal “Y2” of
the 100 Volt transformer. Label this wire “1Y2.”
11. After completing Steps 1 through 10, close up the
electrical control panel. Then refer to the Adjust-
ment section of this manual.
WARNING
VOLTAGE THAT COULD BE FATAL TO HUMAN LIFE
IS PRESENT WITHIN THE ELECTRICAL CONTROL
CIRCUITS. ONLY AUTHORIZED, EXPERIENCED
PERSONNEL SHOULD ATTEMPT THE INSTALLA-
TION AND SERVICING OF ELECTRICAL EQUIP-
MENT.
!
!
