CONNECTIONS
page11
SYSTEM CONNECTIONS
a. Using the antenna input: Connect the antenna terminal from an antenna or cable/satellite
receiver to the antenna input terminal on the DTV-265-D; use the VIDEO button and
the / buttons to set the DTV-265-D's signal source to "Digital TV" or “Analog TV”.
b. Using the RCA Video/Audio input on the back: Connect compatible AV equipment to the
DTV-265-D through the Composite Video and Audio input jacks on the back; use the VIDEO
button and the / buttons to set the DTV-265-D's signal source to "Composite 1".
c. Using the RCA Video/Audio input on the side: Connect compatible AV equipment to the
DTV-265-D through the Composite Video and Audio input jacks on the side; use the VIDEO
button and the / buttons to set the DTV-265-D's signal source to "Composite 2".
d. Using the S-Video and RCA Audio input: Connect AV equipment to the DTV-265-D
through the S-Video and Audio input jacks on the back; use the VIDEO button and the /
buttons to set the DTV-265-D’s signal source to “S-Video”.
e. Using the Component input: The Component input may be used for Progressive scan or
HDTV inputs; use the VIDEO button and the / buttons to set the DTV-265-D's signal
source to "Component".
f. Using the HDMI connector: Connect a PC computer to the DTV-265-D through the HDMI
socket on DTV-265-D. Use the VIDEO button and the / buttons to set the DTV-265-D’s
signal source to “HDMI” .
g. Using the DVI connector: Connect a PC computer to the DTV-265-D through the DVI socket
on DTV-265-D. The Mini-plugged is for audio associated with this type of signal. Use the
VIDEO button and the / buttons to set the DTV-265-D’s signal source to “DVI”.
