Shielded Cat5e, with temperature
range of -34°C to 74°C (-29°F to
165°F)
Safety recommendations
● Follow all of your agency’s required safety procedures when parking and using a
bucket truck during the camera installation.
● Do not install components if the conditions are not safe, such as during adverse
weather situations.
● If possible, inspect wires in the cabinet and traffic pole for any unsafe wear and
replace them if necessary.
Planning your SmartView 360 installation
Determining the number of cameras to install
TrafficLink Detection supports single and dual-camera installations with the SmartView
360 camera. Detection is optimized by installing the camera as high as possible. The
detection ratio, or the distance from the camera to the front of the furthest detection
zone, should be 5:1 or less to the deployed camera height.
Single-camera installations
A single camera is usually sufficient for smaller intersections, except for those with
limited mounting options that do not permit you to install the camera to a minimum
height of 9.14 m (30 ft), or those where an object occludes the camera’s field-of-view.
6.11.19
4
