Mira Advance User Manual

4444
4444
44
13
Spare PartsSpare Parts
Spare PartsSpare Parts
Spare Parts
Section
1.1.
1.1.
1.
Spare P Spare P
Spare P Spare P
Spare P
arar
arar
ar
ts List (memorts List (memor
ts List (memorts List (memor
ts List (memor
y model)y model)
y model)y model)
y model)
405 05 Element Retaining Ring
405 32 Tank Body/Sensor Assembly
405 36 Inlet Shield
405 50 Inlet Sensor
405 56 Wire 78 Multi-connector
405 58 Inlet Connector Assembly
405 73 Memory Control PCB
406 19 Element 9kW/230V 9.8kW/240V
406 20 Element 8kW/230V 8.7kW/240V
406 21 Flow Valve
406 22 Transformer - components identified 'D'
406 25 Seals Pack - components identified 'A'
406 26 Screw Pack - components identified 'B'
406 27 Inlet Filter
406 28 Component Pack - components identified 'C'
406 38 Top Case Insert
406 46 Terminal Block
406 88 Relay Board + Wire 75
430 27 Cover Assembly Memory (with Temperature Potentiometer)
AccessoriesAccessories
AccessoriesAccessories
Accessories
DCV-H:DCV-H:
DCV-H:DCV-H:
DCV-H: An outlet double check valve, designed to prevent the backflow or backsiphonage
of potentially contaminated water, through shower controls which are fitted with a
flexible hose as part of the outlet shower fitting. Available as an optional accessory from
your Caradon Plumbing Solutions stockists.

Mira Advance Specifications

General

Temperature Control	Thermostatic
Warranty	2 Years
Power Ratings	9.8 kW
Water Connection	15 mm
Outlet Connection	1/2"
Water Pressure	0.7 - 10 bar
Cable Entry Points	Bottom entry
Safety Features	Overheat protection
Approvals	WRAS
