Mira Azora Installation And User Guide

7
1062243-W2-N
Specications
Dimensions
Height 367 mm
Width 233 mm
Depth 100 mm
Electrical
Variant
Azora 9.8
Nominal Power at 230 V ac 9.0 kW
Nominal Power at 240 V ac 9.8 kW
RecommendedMCBRating 45 A
Maximum Supply Cable Size 16 mm²
RecommendedRCDRating 30 mA tripping current
RecommendedIsolatorSwitch 45 A double-pole with 3 mm contact separation
ApplianceSealingRating IP X4 - Suitable for installation in Zone 1
Maximum Ambient Temperature 30°C
Minimum Ambient Temperature 2°C
Plumbing
Variant
Azora 9.8
Minimum Dynamic Pressure 70 kPa (0.7 bar)
Maximum Dynamic Pressure 500 kPa (5 bar)
Maximum Static Pressure 1000 kPa (10 bar)
Minimum Static Pressure 20 kPa (0.2 bar)
Maximum Inlet Temperature 30°C
Minimum Inlet Temperature 2°C
Inlet Connection 1/2”BSPMale/15mmCompressionFitting
Maximum Water Hardness 200 ppm CaCO
3
Outlet Connection 1/2”BSPMale
