Installation dimension diagram
Drainage pipe
At least 98’’
At least 6’’
At least 20’’
At least 20’’
At least
12’’
At least 118’’
At least 80’’
Space to the obstruction
Space to the
obstruction
Space to the
obstruction
Space to the ceilin
g
Space to the obstruction
Space to the obstruction
At least 12’’
At least 6’’
At least 6’’
Space to the wall
Space to the wall
Space to the wall
