Technical Specifications
Recommended Amplifier: 15 - 75 W 25 - 75 W 25 - 100 W 25 - 100 W 25 - 150 W 25 - 150 W
(per channel)
Enclosure: 2-way reflex 2-way reflex 2-way reflex 2-way reflex 2-way reflex 3-way reflex
Effective Volume: 3.4 litres 7.0 litres 12.4 litres 17.7 litres 35.7 litres 47.7 litres
Frequency Response ±3dB: 68 Hz - 20 kHz 65 Hz - 20 kHz 52 Hz - 20 kHz 48 Hz - 20 kHz 44 Hz - 20 kHz 40 Hz - 20 kHz
Sensitivity SPL/M @ 2.83V: 86 dB 88 dB 90 dB 90 dB 92 dB 92 dB
Impedance: 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
compatible compatible compatible compatible compatible compatible
(minimum 4.0 Ohms) (minimum 4.0 Ohms) (minimum 4.0 Ohms) (minimum 3.6 Ohms) (minimum 3.8 Ohms) (minimum 3.6 Ohms)
Bass: 1 x 100 mm 1 x 130 mm 1 x 165 mm 1 x 165 mm 2 x 165 mm 3 x 165 mm
DiaDrive unit DiaDrive unit DiaDrive unit DiaDrive unit DiaDrive units DiaDrive units
Treble: Viotex fabric Viotex fabric Viotex fabric Viotex fabric Viotex fabric Viotex fabric
dome treble unit dome treble unit dome treble unit dome treble unit dome treble unit dome treble unit
Dimensions (H x W x D): mm 220 x 145 x 190 255 x 170 x 280 320 x 200 x 325 850 x 200 x 325 950 x 200 x 330 1030 x 260 x 375
Weight (per loudspeaker): 2.5 kg 4.3 kg 7.0 kg 14.7 kg 17.8 kg 22.8 kg
m30i m31i m32i m33i m34i m35i
Recommended Amplifier: 25 - 100 W 25 - 125 W 25 - 100 W Integrated 150 W
(per channel) active subwoofer
Enclosure: 2-way reflex 2-way reflex 2-way reflex reflex
Effective Volume: 5.2 litres 9.7 litres 4.5 litres 35.0 litres
Frequency Response ±3dB: 75 Hz - 20 kHz 56 Hz - 20 kHz 75 Hz - 20 kHz 30 Hz - 165 Hz
Sensitivity SPL/M @ 2.83V: 89 dB 91 dB 89 dB n /a
Impedance: 8 Ohms 8 Ohms 8 Ohms n /a
compatible compatible compatible
(minimum 4.7 Ohms) (minimum 4.2 Ohms) (minimum 5.6 Ohms)
Bass: 2 x 100 mm 2 x 100 mm 2 x 100 mm 1 x 250 mm
DiaDrive units DiaDrive units Coaxial units Pulp fibre unit
Treble: Viotex fabric Viotex fabric - -
dome treble unit dome treble unit
Dimensions (H x W x D): mm 135 x 500 x 130 165 x 430 x 230 230 x 360 x 110 410 x 280 x 500
Weight (per loudspeaker): 2.5 kg 6.7 kg 2.4 kg 17.5 kg
m3c1i m3c2i m3dsi m3as
Should a fault occur with your loudspeakers please return them as a pair, even if only
one unit appears to be faulty. Please pack them correctly, using the original packing.
Product for service should be returned to the appointed dealer from whom you
purchased the product. If you experience difficulties or there is no Mission dealer
in your area, contact the Mission distributor for your country or the Main Service
Centre for your region.
Product Service
Use a slightly dampened cloth to clean your cabinets and occasionally, a light spray
polish to protect their sheen. If necessary clean grilles carefully with a soft brush.
Loudspeaker
Maintenance
8
Mission reserves the right to change all specifications without notice. E & OE
