28
MIT 160
Diaphragm Maintenance
MIT 550
MIT 1500
MAINTENANCE
Clean the pump with a compatible cleaning uid before starting maintenance, if the uid transferred
by the pump has drying and frosting characteristics. Otherwise, pump maintenance will be more
expensive and difcult. Control bolt connections in each use. Tighten loose connections with a
suitable wrench. Replace required connections.
21
10
20
17
18
3
7
3 Main Body
20 Oil Seal
21 Bumper
10 Srod, Diaphragm
17 Plate, Inner Diaphragm
7 Diaphragm
18 Plate, Outher Diaphragm
20
21
10
17
18
3
7
3 Main Body
20 Srod, Diaphragm
21 Oil Seal
10 Bumper
17 Plate, Inner Diaphragm
7 Diaphragm
18 Plate, Outher Diaphragm
3
20
21
10
17
18
7
3 Main Body
20 Srod, Diaphragm
21 Oil Seal
10 Bumper
17 Plate, Inner Diaphragm
7 Diaphragm
18 Plate, Outher Diaphragm
