12
Chapter 2
System Components
This chapter introduces the components of the motherboard.
Major Components
Figure 2-1. Major Components of System Board
DIMM Sockets
Socket 7
U6
U5
U9
U1
U11
U4
TAG1
VT82C686A
ROM BIOS
ES1989
VT82C8501
TAG RAM
Cache
PCI Slots
