MiTAC 5114VU - Jumper Settings

18
Jumper Settings
NOTE: Jumpers not described in this chapter are reserved for factory
use only. Do not change the default settings.
AMD K6 Jumper Settings
JP
CPU
JP4 JP5 JP6 JP7 JP8 JP9 JP10 JP11 JP12 JP13 JP14 JP15
K6-2/K6 III
400 (2.2V)
close open close open close open open open close close close open
K6-2/K6 III
400 (2.4V)
close open close open open close open open close close close open
K6-2/K6 III
450 (2.2V)
close close close open close open open open close close close open
K6-2/K6 III
450 (2.4V)
close close close open open close open open close close close open
K6-2
475 (2.2V)
open close close open close open open open open close close open
K6-2
475 (2.4V)
open close close open open close open open open close close open
K6-2
500 (2.2V)
open close close open close open open open close close close open
K6-2
533 (2.2V)
open open close open close open open open open open close open
K6-2
550 (2.2V)
open open close open close open open open close close close open
Table 3-3. CPU Jumper Settings
Other Jumper Settings
Jumper Definition Setting
JP3 CMOS setting 1-2: Normal
2-3: Clear CMOS *
* To clear the RTC and CMOS RAM, set JP3 to 2-3 for one
second, and set it back to 1-2 again.
Table 3-4. CMOS Jumper Settings
