MiTAC 5114VU - Connector Definitions

17
Connector Definitions
Internal Connectors
Connector Definition
J2 pin 3-4
pin 5-6
pin 11-13
pin 15-16
pin 19-20
Sleep LED
HDD LED
Power LED
Power button
Reset
BAT1 Battery
CN1 Power supply
DIMM 1~2 DIMM sockets
FAN1 CPU fan
FDD1 FDD
IDE1, IDE2 IDE
PCI 1~4 PCI slots
Socket 7 CPU socket
Table 3-1. Internal Connector Definition
External Connectors
Connector Definition
CD1 CD IN
COM1 COM1
GAME1 Game/MIDI
Mic-in / Line-in / Line-out
PJ1 PIO port
PS1 PS/2 keyboard/mouse
USB1 USB (rear)
VGA1 VGA
Table 3-2. External Connector Definition
