Installing the applications card
14
Applications Card CPU2-S
syd-0620/1.1 – R4.0 – 01.2016
Take the applications card in operation
To take the applications card in operation, proceed as follows:
1. Switch on the communication server.
Switching on the communication server also powers up the applications
card. You can see this on the the LED's On/Off key which now turns steady
orange.
2. From your administration PC, open your communication server's WebAd-
min and log on.
3. Navigate to the card view(Configuration / System / Cards and modules.
The applications card is now entered in slot 2 under the name CPU2-S, and
the operating status is Available.
4. Click the Confirm button at the end of the slot line.
The applications card is now registered on the communication server. The
operating status changes from Available to In operation.
5. Start the applications card, by pressing the On/Off pushbutton on the card.
6. Starting the applications card is similar to starting a computer, and may take
a while. The On/Off push button LED turns green after the booting process.
On the WebAdmin menu tree, on the uppermost level after the Configura-
tion menu, the Multimedia menu is displayed.
Note concerning the hard disc LED:
If the applications card is switched on, the HDD LED lights during
an access to the hard disc.
If the applications card is switched off, the HDD LED lights perma-
nently
Set up the applications card
Below, you can check the communication server IP address, choose a pass-
word for the applications card and load the OIPlicence file. A setup wizard will
guide you through the configurations:
1. Open the Multimedia / Basic configuration window and check under Current
IP address whether your communication server IP address has been en-
tered correctly.
If this is not the case, the setup wizard has probably detected other commu-
nication servers on your subnet. You can see all the IP addresses of de-
tected communication servers under Communication servers in subnet. Se-
