5000 CP Phone User Guide Supplement for v3.2, September 2009 Page 3
5000 CP Devices
5000 CP v3.2 includes support for the following devices:
• “8528 and 8568 Digital Telephones” below
• “5304 IP Phone” on page 5
• “5320 IP Phone” on page 6
• “5312/5324 IP Phones” on page 7
• “12-Button and 48-Button Programmable Key Modules” on page 8
8528 and 8568 Digital Telephones
The new Mitel 8528 and 8568 digital telephones replace the existing 8520 and 8560 digital
telephones, respectively. The 8528 provides a 2-line Liquid Crystal Display (LCD). The 8568
provides a 6-line LCD with menu buttons. Images of both phones appears below.
1 – Liquid Crystal Display (LCD) 5 – Programmable buttons
2 – Ring/Message Indicator 6 – External speaker
3 – Feature buttons 7 – Handset
4 – Dialpad buttons 8 – Menu buttons (8568 only)
7 1 2
3
4
6
5
3
4
6
8
5
7 1 2
8528 – 2-Line Digital Telephone
8568 – 6-LIne Digital Telephone
