18
Tabella 7.2.A
7.3 REQUEST OF ASSISTANCE
For any information regarding Use, Maintenance, Installation, etc.. we remain at your disopsal. The Customer has to clearly
formulate their questions & send us a fax with a detailed description of the troubles met. For eventual explanations we suggest
you reference this handbook and to the instructions listed in the paragraph 1.2.
ITW/AMP
FAX: 1-800-426-7019
Phone: 1-800-322-4204
TROUBLE
Pressing the foot pedal the machine
works properly, but once the pedal is
released you can note a certain delay in
the re-positioning of the driver blade
and/or vertical clamp cylinders
Wishing to insert several V-nails one upon
the other in the same point, they do not
stack properly or tilt during their
insertion
Wishing to insert several V-nails one upon
the other in the same point, they do not
stack properly or tilt during their
insertion
Wishing to insert several V-nails one upon
the other in the same point, they do not
stack properly or tilt during their
insertion
Wishing to insert several V-nails one upon
the other in the same point, they do not
stack properly or tilt during their
insertion
POSSIBLE CAUSE
Faulty or jammed valves
Unsuitable V-nails
Poor frames clamping (the frame
moves during the V-nail
insertion)
Wore and torn driver blade
Jammed driver blade
REMEDY
- Remove the surplus of oil and/or water
- Replace the foot pedal valve
- Replace the faulty control valves
Replace the V-nail with suitable ones
- Check and replace the vertical and
frontal clamping positions
- Increase the clamp pressure
- Replace the pressure pad with the proper
one
Replace the driver blade
Clean the driver blade’s upper part
removing any material jamming the
upper profile
