COMPONENT
• V-NAILS DRIVER BLADE
• V-NAILS CLAW HEADS “L”
• SHAPED SUPPORT (V-NAILS GUIDE)
• VALVES-REDUCERS-REGULATORS
• VERTICAL AND HORIZONTAL CLAMPING
GASKETS
8.1 SPARE PARTS LIST
Even though the machine has been submitted to several tests and functional checks, we have listed below the components that
we suggest you have a minimum and sufficient set of spare parts to guarantee the shortest downtime as possible.
TABLE 8.1 - A
8. SPARE PARTS
8.2 SPARE PARTS ORDERING
We remind you that only a qualified technician can repair the machine.
Thus, we suggest the intervention of ITW/AMP or your local distributor’s Center of Technical Assistance, which has the
qualified staff, proper equipment and tools, and who uses original spare parts.
To order the above listed spare parts, send by fax or letter the following data:
• Model of the Machine
• Code of mechanical drawing
• Reference number of spare part or group indicated on the mechanical drawing
• Code number of single or group spare part
9 DEMOLITION
9.1 DEMOLITION
At the act of demolition it is necessary to separate the parts in plastic material from electric components. Sometimes they must
be sent to different centers respecting the current Norms.
Concerning the machine’s metallic mass, it is enough to subdivide the steel parts and those of other metals or alloys, for a
proper recycling by smelting.
10. ATTACHMENTS
10.1 DECLARATIONS
You can find here attached the following declarations
• Declaration of conformity to the Norm 89/392/CEE
10.2 SCHEMES
You can find attached here the following schemes:
• (A) Mechanic Schemes
• (B) Pneumatic Scheme
• (C) Plates location
• (D) Sharpening Table
