Mitsubishi Electric A800-E User Manual

(N) Operation via communication and its settings
PARAMETER
49
2
GROUP
N
• Real time monitor
For the details of the register numbers and the monitor items for the real time monitor, refer to the description of Pr.52 in the
Instruction Manual (Detailed) of the FR-A800/FR-F800 inverter.
• Parameters
Pr. Register Parameter name Read/write Remarks
0 to 999
41000 to
41999
Refer to the Instruction Manual
(Detailed) of the FR-A800/FR-F800
inverter for parameter names.
Read/write The parameter number +41000 is the register number.
C2 (902) 41902
Terminal 2 frequency setting bias
(frequency)
Read/write
C3 (902)
42092
Terminal 2 frequency setting bias
(analog value)
Read/write Analog value (%) set to C3 (902)
43902
Terminal 2 frequency setting bias
(terminal analog value)
Read
Analog value (%) of the voltage (current) applied to
terminal 2
125 (903) 41903
Terminal 2 frequency setting gain
(frequency)
Read/write
C4 (903)
42093
Terminal 2 frequency setting gain
(analog value)
Read/write Analog value (%) set to C4 (903)
43903
Terminal 2 frequency setting gain
(terminal analog value)
Read
Analog value (%) of the voltage (current) applied to
terminal 2
C5 (904) 41904
Terminal 4 frequency setting bias
(frequency)
Read/write
C6 (904)
42094
Terminal 4 frequency setting bias
(analog value)
Read/write Analog value (%) set to C6 (904)
43904
Terminal 4 frequency setting bias
(terminal analog value)
Read
Analog value (%) of the current (voltage) applied to
terminal 4
126 (905) 41905
Terminal 4 frequency setting gain
(frequency)
Read/write
C7 (905)
42095
Terminal 4 frequency setting gain
(analog value)
Read/write Analog value (%) set to C7 (905)
43905
Terminal 4 frequency setting gain
(terminal analog value)
Read
Analog value (%) of the current (voltage) applied to
terminal 4
C12 (917) 41917 Terminal 1 bias frequency (speed) Read/write
C13 (917)
42107 Terminal 1 bias (speed) Read/write Analog value (%) set to C13 (917)
43917
Terminal 1 bias (speed)
(terminal analog value)
Read Analog value (%) of the voltage applied to terminal 1
C14 (918) 41918 Terminal 1 gain frequency (speed) Read/write
C15 (918)
42108 Terminal 1 gain (speed) Read/write Analog value (%) set to C15 (918)
43918
Terminal 1 gain (speed)
(terminal analog value)
Read Analog value (%) of the voltage applied to terminal 1
C16 (919) 41919
Terminal 1 bias command (torque/
magnetic flux)
Read/write
C17 (919)
42109 Terminal 1 bias (torque/magnetic flux) Read/write Analog value (%) set to C17 (919)
43919
Terminal 1 bias (torque/magnetic flux)
(terminal analog value)
Read Analog value (%) of the voltage applied to terminal 1
C18 (920) 41920
Terminal 1 gain command (torque/
magnetic flux)
Read/write
C19 (920)
42110 Terminal 1 gain (torque/magnetic flux) Read/write Analog value (%) set to C19 (920)
43920
Terminal 1 gain (torque/magnetic flux)
(terminal analog value)
Read Analog value (%) of the voltage applied to terminal 1
C29 (925)
42115
Motor temperature detection
calibration (analog input)
Read/write
43925
Motor temperature detection
calibration (analog input)
(terminal analog value)
Read
Analog value (%) between terminals TH1 and TH2 of the
FR-A8AZ
C30 (926) 41926 Terminal 6 bias frequency (speed) Read/write
C31 (926)
42116 Terminal 6 bias (speed) Read/write Analog value (%) set to C31 (926)
43926
Terminal 6 bias (speed)
(terminal analog value)
Read
Analog value (%) of the voltage applied to terminal 6 of
the FR-A8AZ
C32 (927) 41927 Terminal 6 gain frequency (speed) Read/write
C33 (927)
42117 Terminal 6 gain (speed) Read/write Analog value (%) set to C33 (927)
43927
Terminal 6 gain (speed)
(terminal analog value)
Read
Analog value (%) of the voltage applied to terminal 6 of
the FR-A8AZ
C34 (928) 41928 Terminal 6 bias command (torque) Read/write
