Mitsubishi Electric A800 Programming Manual

58
CC-Link communication
CC-Link parameter
2.2 CC-Link parameter
2.2.1 CC-Link extended setting (Pr.544)
The functions of the remote register can be extended.
 The program used for the conventional series inverter option (FR-A5NC) can be used.
 When using the double, quadruple, or octuple settings of the CC-Link Ver.2, station data of the master station must be set to double, quadruple,
or octuple. (If the master station is CC-Link Ver.1, this setting is not available.)
NOTE
• The setting becomes valid after inverter reset.
Parameter
number
Name
Initial
value
Setting
range
Description
CC-Link
version
544
CC-Link
extended setting
0
0
1
Occupies one station (FR-A5NC compatible)

1 Occupies one station
12 
2
Occupies one station, double
14  Occupies one station, quadruple
18  Occupies one station, octuple
24
 Occupies one station, quadruple
28
 Occupies one station, octuple
100 1 Occupies one station (PLC function)
112

2
Occupies one station, double (PLC function)
114  Occupies one station, quadruple (PLC function)
118
 Occupies one station, octuple (PLC function)
128 Occupies one station, octuple (PLC function)
