4-386 Detailed explanation of Robot Status Variable
4MELFA-BASIC V
P_Curr
[Function]
Returns the current position (X, Y, Z, A, B, C,L1,L2) (FL1, FL2).
[Format]
[Terminology]
<Position Variables> Specifies the position variable to assign.
<Mechanism Number> Enter the mechanism number. 1 to 3, If the argument is omitted, 1 is set as the
default value.
[Reference Program]
1 Def Act 1,M_In(10)=1 GoTo *LACT ' Defines interrupt.
2 Act 1=1 ' Enables interrupt.
3 Mov P1
4 Mov P2
5 Act 1=0 ' Disables interrupt.
:
100 *LACT
101 P100=P_Curr ' Loads the current position when an interrupt signal is
received.
102 Mov P100,-100 ' Moves 100 mm above P100 (i.e, -100 mm in the Z direc-
tion of the tool).
103 End ' Ends the program.
[Explanation]
(1) This can be used to identify the current position.
(2) This variable only reads the data.
[Reference]
J_Curr, P_Fbc
Example)<Position Variables>=P_Curr [(<Mechanism Number>)]
