103
PARAMETERS
4
4.2.28 Applied motor (Pr. 71)
Pr. 71 "applied motor"
Set the motor used.
<Setting>
• Refer to the following list and set this parameter according
to the motor used.
• For the 5.5K and 7.5K, the Pr. 0 and Pr. 12 settings are automatically changed depending on the Pr. 71
setting.
Parameter
Number
Factory
Setting
Setting Range
71 0 0 to 8, 13 to 18, 20, 23, 24
Pr. 71
Setting
Thermal Characteristics of Electronic Overcurrent Protection
Motor
Standard
Constant
Torque
0 Thermal characteristics of a standard motor 
1 Thermal characteristics of a Mitsubishi constant-torque motor 
2
Thermal characteristics matching a standard motor
5-point flexible V/F characteristics (Refer to page 125)

20
Thermal characteristics for advanced magnetic flux vector control of the Mitsubishi standard
motor SF-JR4P (1.5kW (2HP) or less)

3 Standard motor
Select "offline auto tuning setting".

13 Constant-torque motor 
23
Mitsubishi general-purpose motor SF-JR4P
(1.5kW (2HP) or less)

4 Standard motor
Read auto tuning data, settings can be
changed.

14 Auto tuning data can be read or set anew. 
24
Mitsubishi general-purpose motor SF-JR4P
(1.5kW (2HP) or less)

5 Standard motor
Star connection
Motor constants can
be entered directly.

15 Constant-torque motor 
6 Standard motor
Delta connection

16 Constant-torque motor 
7 Standard motor
Standard motor
Direct motor constant
entry and offline auto
tuning

17 Constant-torque motor 
8 Standard motor
Delta connection

18 Constant-torque motor 
Pr. 71 0, 2, 3 to 8, 20, 23, 24 1, 13 to 18
Pr. 0 3% 2%
Pr. 12 4% 2%
Note: 1. When "8888" or "9999" is set in Pr. 19, "2" cannot be set in Pr. 71. To set "2" in Pr. 71, set the
appropriate value (other than "8888" and "9999") in Pr. 19.
2. When "2" is set in Pr. 71, Pr. 100 to Pr. 109 are displayed on the parameter unit (FR-PU04). In
other settings, if any of Pr. 100 to Pr. 109 settings is changed, the new setting is not displayed in
the "Default parameter list" and "Set parameter list".
3. Refer to Pr. 96 for offline auto tuning.
4. Set any of "3, 7, 8, 13, 17 and 18" to perform offline auto tuning.
CAUTION
Set this parameter correctly according to the motor used.
Incorrect setting may cause the motor to overheat and burn.
Related parameters
Pr. 0 "torque boost"
Pr. 12 "DC injection brake voltage"
Pr. 19 "base frequency voltage"
Pr. 60 "intelligent mode selection"
Pr. 80 "motor capacity"
Pr. 81 "number of motor poles"
Pr. 96 "auto tuning setting/status"
Pr. 100 to Pr. 109
(V/F frequency/voltage)
