SPECIFICATIONS
7
 Operation panel (FR-DU04)
 Parameter unit (FR-PU04)
<Outline drawing> <Panel cutting dimension drawing>
(Unit: mm (inches))
Select the installation screws whose length will not exceed the effective depth of the installation screw threads.
<Outline drawing> <Panel cutting dimension drawing>
(Unit: mm (inches))
Select the installation screws whose length will not exceed the effective depth of the installation screw threads.
2-M3 hole
Effective depth 4.5
2- 4 hole
φ
19.75 (0.78)
3.25 (0.13)
16.5 (0.65)
23.75 (0.94)
46.5 (1.83)
17 (0.67)
54 (2.13)
81.5 (3.21)
72 (2.83)
15 (0.59) 10.5 (0.41)
20 (0.79)
54 (2.13)
16.5 (0.65)46.5 (1.83)
24 (0.94)
3.5 (0.14)
5-M3 threads
Effective depth 4.5
5- 4 hole
125 (4.92)
72 (2.83)
15 (0.59) 10.5 (0.41)
40 (1.57)
80 (3.15)
48 (1.89)
24 (0.97)
13 (0.51)
20 (0.79)
21.5 (0.85)
14.5 (0.57)
40 (1.57)
11.75 (0.46)
81.5 (3.21)
17 (0.67)
16.5 (0.65)
1.5 (0.06)
18.5 (0.73)
23.75 (0.93)
1.25 (0.05)
1.5 (0.06)
13 (0.51)
