108
PARAMETERS
4.2.33 Alarm code output selection (Pr. 76)
Pr. 76 "alarm code output selection"
When an alarm occurs, its code can be output as a 4-bit digital signal from the open collector output
terminals. When programmed operation has been selected, this parameter also serves to output a group
operation signal.
The alarm code can be read by a programmable controller, etc. to show its remedy on a display. Also you
can look at the progress of programmed operation.
<Setting>
•Alarm code output
Parameter
Number
Factory Setting Setting Range
76 0 0 to 3
Pr. 76 Setting
Output Terminals
SU IPF OL FU
0 Alarm code is not output. (Depends on Pr. 190 to Pr. 195).
1 Alarm code bit 3 Alarm code bit 2 Alarm code bit 1 Alarm code bit 0
2
When an alarm occurs, an alarm code signal is output. (Output signal is the same as in 1.)
When operation is normal, an operation status signal is output. (Output signal is the same as in 0.)
3
(during programmed
operation)
Output at time-out During group 3 operation During group 2 operation During group 1 operation
Note: 1. For alarm code definitions, refer to page 202.
2. The Pr. 76 setting overrides the Pr. 190 to Pr. 195 settings. Therefore, if you assign other signals
to output terminals SU, IPF, OL and FU using Pr. 190 to Pr. 195, these terminals provide the
output signals as listed above when any of "1 to 3" is set in Pr. 76. This should be noted when
using the functions which use the output signals to exercise control.
Related parameters
Pr. 79 "operation mode selection"
Pr. 190 to Pr. 195
(output terminal function selection)
Pr. 200 to Pr. 231
(programmed operation)
Example: When using the brake sequence functions (Pr. 278 to Pr. 285), assign the brake
opening request signal (BOF) to the RUN terminal by setting "20" in Pr. 190.
