FX3G/FX3U/FX3UC Series Programmable Controllers
Programming Manual - Basic & Applied Instruction Edition
13 High-Speed Processing – FNC 50 to FNC 59
13.3 FNC 52 – MTR / Input Matrix
13.3 FNC 52 – MTR / Input Matrix
Outline
This instruction reads matrix input as 8-point input × "n"-point output (transistor) in the time division method.
1. Instruction format
2. Set data
3. Applicable devices
Explanation of function and operation
1. 16-bit operation (MTR)
An input signal of 8 points × "n" columns is controlled in the time division method using 8 inputs and "n"
transistor outputs . Each column is read in turn, and then output to .
• For each output, the I/O processing is executed immediately in turn in interrupt at every 20 ms under consideration
of the input filter response delay of 10 ms.
Operand Type Description Data Type
Input device (X) number of matrix signal input
X000, X010, X020 … final input device number
(Only "0" is allowed in the least significant digit of device numbers.)
Bit
Head device (Y) number of matrix signal output
Y000, Y010, Y020 … final output device number
(Only "0" is allowed in the least significant digit of device numbers.)
Bit
Head bit device (Y, M or S) number of ON output destination
Y000, Y010, Y020 … final Y number, M000, M010, M020 … final M number or S000,
S010, S020 … final S number
(Only "0" is allowed in the least significant digit of device numbers.)
Bit
n Number of columns in matrix input (K2 to K8 or H2 to H8) 16-bit binary
Oper-
and
Type
Bit Devices Word Devices Others
System User Digit Specification System User
Special
Unit
Index Constant
Real
Number
Charac-
ter String
Pointer
XYMTCSD  .b KnX KnY KnM KnS T C D R U\G VZModify K H E "  "P
3
3
33 3
n 33
FNC 52
MTR
16-bit Instruction
9 steps
MTR
Mnemonic Operation Condition
Continuous
Operation
−
Mnemonic Operation Condition
32-bit Instruction
S
D 1
D 2
S
D 1
D 2
S
D 1 D 2
Command
input
(normally ON)
FNC 52
MTR
nS D 1 D 2
Number
of
columns
Input
number
Output
number
ON
output
destination
