What to do if the PWR LED is turned off on my Mitsubishi Electric Controller?
If the PWR LED is off on your Mitsubishi Electric Controller, it may be due to an improper voltage supply. Ensure the power source provides the correct voltage. If the PWR LED turns on after correcting the power supply, it indicates that the service power supply might be shorted or overloaded. Try reconnecting the modules and wiring one by one to identify the cause.
Why is the BAT LED on my Mitsubishi Electric FX5U illuminated?
The BAT LED on your Mitsubishi Electric Controller might be on because the battery is not installed properly. Make sure the battery is correctly installed. Also, if the battery voltage is low, replace the battery with a new one.
General| Model | FX5U |
|---|---|
| Series | MELSEC iQ-F |
| Built-in SD Card Slot | Yes |
| Power Supply | 24 VDC |
| Type | PLC |
| I/O Points | Up to 256 points (with expansion) |
| Program Capacity | 64, 000 steps |
| Execution Speed | 34 ns/instruction (LD instruction) |
| Communication Ports | Ethernet, USB, RS-485 |
| Built-in USB Port | Yes (USB 2.0) |
| Built-in RS-485 Port | Yes |
| Built-in Ethernet Port | Yes |
| Built-in Positioning | Yes |
| Communication Protocols | Ethernet/IP, Modbus TCP/IP, MC Protocol, SLMP |
| Programming Language | Ladder Logic, Structured Text, Function Block Diagram |
| Memory | Flash memory |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 75°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Shock Resistance | 147 m/s2, Duration: 11 ms, Test direction: X, Y, Z axes |
| Weight | Approx. 0.4 kg |
Safety measures for system design to prevent accidents and damage.
Safety guidelines for physically installing the PLC and its components.
Safety measures for electrical wiring to prevent hazards and malfunctions.
Safety steps for initial operation and ongoing upkeep of the PLC.
Guidelines for safe operation of the PLC and connected equipment.
Identification and description of the physical components and connectors of the CPU module.
Details on AC power supply ratings, fuses, rush current, and power capacity.
Technical data for 24V DC input, including voltage, current, impedance, and response time.
Specifications for relay and transistor output types, including load limits and response time.
Guidelines for connecting extension devices, managing I/O points, and system limits.
Rules for the maximum number of modules that can be connected.
Constraints on the total number of I/O points and remote I/O points in a system.
How to check power supply capacity and manage current consumption of connected devices.
Guidelines and examples for configuring and reconfiguring PLC systems.
Recommendations for selecting an appropriate installation location and maintaining spacing.
Methods for installing PLC modules, either on DIN rail or directly with screws.
Step-by-step instructions for mounting and removing modules from a DIN rail.
Steps for direct mounting of modules using screws, including hole pitches.
Steps and precautions before starting wiring, including preparing parts and grounding.
A systematic approach to diagnosing and resolving PLC errors and issues.
