MODBUS/TCP Interface Module User's Manual
-QJ71MT91
-GX Configurator-MB (SW1D5C-QMBU-E)

Table of Contents

Questions and Answers

  • O
    osmallAug 3, 2025
    What to do if the ERR. LED is on for Mitsubishi Electric Control Unit?
    • A
      Amanda WoodAug 3, 2025
      If the ERR LED is illuminated on your Mitsubishi Electric Control Unit, it could be due to several reasons. First, verify the intelligent function module switch 1 (operation mode setting) value and correct it, ensuring it's within the setting range. Second, confirm that the QJ71MT91 module is mounted with the correct Q mode QCPU. Finally, ensure the module isn't in hardware or self-loopback test mode; restart the test after verifying the QJ71MT91 mounting status. If the ERR LED persists, a hardware fault might be the cause, necessitating a change of the QJ71MT91.
  • A
    Angel EdwardsAug 17, 2025
    How to fix RUN LED turned off on Mitsubishi Electric Control Unit?
    • S
      Steven EsparzaAug 17, 2025
      If the RUN LED on your Mitsubishi Electric Control Unit is off, there are several potential causes. First, ensure the QJ71MT91 is properly mounted by switching the power off and remounting it. Second, check the power supply capacity and change the power supply module if necessary. Third, inspect the programmable controller CPU; if faulty, take corrective actions as described in the QCPU User's Manual (Hardware Design, Maintenance and Inspection). Finally, check for a watch dog timer error (X1F); try resetting the programmable controller CPU or power cycling it. If the problem continues after resetting, it might indicate a hardware fault, requiring a hardware test and replacement of the QJ71MT91.

Summary

SAFETY PRECAUTIONS

Design Precautions

Precautions for designing safe systems and preventing malfunctions.

Installation Precautions

Guidelines for safely installing hardware modules to prevent damage or hazards.

Wiring Precautions

Safety measures and best practices for electrical wiring to prevent shocks or damage.

Setup and Maintenance Precautions

Precautions for setting up and maintaining the module to ensure safety and reliability.

Operating Precautions

Guidelines for safe operation of the module to prevent damage, accidents, or fire.

2 SYSTEM CONFIGURATION

3 SPECIFICATIONS

3.1 Performance Specifications

Detailed performance specifications of the QJ71MT91 module, including transmission rates and connection limits.

4 MODBUS STANDARD FUNCTIONS

4.1 MODBUS Standard Function Support List

A list of standard MODBUS functions supported by the QJ71MT91, categorized by master and slave functions.

5 FUNCTIONS

5.2 Master Function

Explanation of the QJ71MT91's capabilities when acting as a master in MODBUS/TCP communication.

5.3 Slave Function

Explanation of the QJ71MT91's capabilities when acting as a slave in MODBUS/TCP communication.

6 PRE-OPERATIONAL PROCEDURES AND SETTING

6.6 Intelligent Function Module Switch Setting

Detailed guide on configuring the intelligent function module switches for operation mode, communication settings, and IP addresses.

7 PARAMETER SETTING

7.1 Parameter Settings and Setting Procedure

Overview of parameter types and methods for setting parameters on the QJ71MT91 module.

7.2 Basic Parameters

Detailed configuration of basic parameters, including TCP/UDP/IP settings, routing, and GX Developer connection.

7.3 Automatic Communication Parameters

Settings for the automatic communication function, including target station IP, module ID, and timers.

7.4 MODBUS Device Assignment Parameters

Configuration for mapping MODBUS devices to programmable controller CPU memory or buffer memory.

8 UTILITY PACKAGE (GX Configurator-MB)

8.4 Initial Setting

Guide to setting initial parameters using the utility package, bypassing the need for sequence programs.

8.6 Monitor;Test

Procedures for monitoring module status, I/O signals, and performing tests like PING test using the utility.

9 PROGRAMMING

10 DEDICATED INSTRUCTIONS

11 TROUBLESHOOTING
