α
2 Simple Application Controllers
Wiring 4
ENG-17
ENG
4. Wiring
4.1 Installation Wiring Notes
The wiring of
α
2 Series has been designed to be safe and easy. A technician or engineer
trained in the local and national electrical standards should perform all tasks associated
with the electrical wiring of the
α
2 Series controllers. Turn OFF the Power before
performing any wiring operations.
• Input and output cables should not be run through the same multicore cable or share the
same wire.
• Do not lay input/output cables near high voltage power cables.
• Input and output cable length must be than 30m (98' 5").
Allow for voltage drop and noise interference with input/output lines used over an extended
distance. Please use wire that is properly sized for the current load.
The terminal will accept a 3 mm flathead screwdriver.
