1Error list
Error no. H8800 * 1-68
H8800 * One of the errors below is detected. Please take measures corresponding to an error message.
Error message ASIC communication error
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error message ASIC CRC error
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error message ASIC short frame error
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error message ASIC overrunning error
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error message ASIC connector connection error
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error message ASIC 0byte transmission
Cause A failure was detected in the communication within the controller.
The internal temperature of the controller may be high.
For the CR800-R/CR800-Q controller, the following conditions may also be the cause.
・ The power on timing may be incorrect.
・ The cable between the controller and the robot CPU may have a fault.
Measures Confirm that the controller filter has no clogging and the ambient temperature is 40 ℃ or less. If the error
persists after taking above measures, contact the manufacturer.
For the CR800-R/CR800-Q controller, turn on the switch of the controller, then of the robot CPU. Check
the cable connection between the robot CPU and the controller.
Error No. Error cause and measures
