Output signal display (Request code: 175/553)
PleaserefertoTable2onrelevantwiringdiagramwhilstusingthefollowing.
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 0 1 xx80
1 0 0 0 0 0 0 1 xx81
0 1 0 0 0 0 0 1 xx82
1 1 0 0 0 0 0 1 xx83
0 0 1 0 0 0 0 1 xx84
1 0 1 0 0 0 0 1 xx85
0 1 1 0 0 0 0 1 xx86
1 1 1 0 0 0 0 1 xx87
0 0 0 1 0 0 0 1 xx88
1 0 0 1 0 0 0 1 xx89
0 1 0 1 0 0 0 1 xx8A
1 1 0 1 0 0 0 1 xx8B
0 0 1 1 0 0 0 1 xx8C
1 0 1 1 0 0 0 1 xx8D
0 1 1 1 0 0 0 1 xx8E
1 1 1 1 0 0 0 1 xx8F
0 0 0 0 1 0 0 1 xx90
1 0 0 0 1 0 0 1 xx91
0 1 0 0 1 0 0 1 xx92
1 1 0 0 1 0 0 1 xx93
0 0 1 0 1 0 0 1 xx94
1 0 1 0 1 0 0 1 xx95
0 1 1 0 1 0 0 1 xx96
1 1 1 0 1 0 0 1 xx97
0 0 0 1 1 0 0 1 xx98
1 0 0 1 1 0 0 1 xx99
0 1 0 1 1 0 0 1 xx9A
1 1 0 1 1 0 0 1 xx9B
0 0 1 1 1 0 0 1 xx9C
1 0 1 1 1 0 0 1 xx9D
0 1 1 1 1 0 0 1 xx9E
1 1 1 1 1 0 0 1 xx9F
0 0 0 0 0 1 0 1 xxA0
1 0 0 0 0 1 0 1 xxA1
0 1 0 0 0 1 0 1 xxA2
1 1 0 0 0 1 0 1 xxA3
0 0 1 0 0 1 0 1 xxA4
1 0 1 0 0 1 0 1 xxA5
0 1 1 0 0 1 0 1 xxA6
1 1 1 0 0 1 0 1 xxA7
0 0 0 1 0 1 0 1 xxA8
1 0 0 1 0 1 0 1 xxA9
0 1 0 1 0 1 0 1 xxAA
1 1 0
1 0 1 0 1 xx
AB
0 0 1 1 0 1 0 1 xxAC
1 0 1 1 0 1 0 1 xxAD
0 1 1 1 0 1 0 1 xxAE
1 1 1 1 0 1 0 1 xxAF
0 0 0 0 1 1 0 1 xxB0
1 0 0 0 1 1 0 1 xxB1
0 1 0 0 1 1 0 1 xxB2
1 1 0 0 1 1 0 1 xxB3
0 0 1 0 1 1 0 1 xxB4
1 0 1 0 1 1 0 1 xxB5
0 1 1 0 1 1 0 1 xxB6
1 1 1 0 1 1 0 1 xxB7
0 0 0 1 1 1 0 1 xxB8
1 0 0 1 1 1 0 1 xxB9
0 1 0 1 1 1 0 1 xxBA
1 1 0 1 1 1 0 1 xxBB
0 0 1 1 1 1 0 1 xxBC
1 0 1 1 1 1 0 1 xxBD
0 1 1 1 1 1 0 1 xxBE
1 1 1 1 1 1 0 1 xxBF
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 1 1 xxC0
1 0 0 0 0 0 1 1 xxC1
0 1 0 0 0 0 1 1 xxC2
1 1 0 0 0 0 1 1 xxC3
0 0 1 0 0 0 1 1 xxC4
1 0 1 0 0 0 1 1 xxC5
0 1 1 0 0 0 1 1 xxC6
1 1 1 0 0 0 1 1 xxC7
0 0 0 1 0 0 1 1 xxC8
1 0 0 1 0 0 1 1 xxC9
0 1 0 1 0 0 1 1 xxCA
1 1 0 1 0 0 1 1 xxCB
0 0 1 1 0 0 1 1 xxCC
1 0 1 1 0 0 1 1 xxCD
0 1 1 1 0 0 1 1 xxCE
1 1 1 1 0 0 1 1 xxCF
0 0 0 0 1 0 1 1 xxD0
1 0 0 0 1 0 1 1 xxD1
0 1 0 0 1 0 1 1 xxD2
1 1 0 0 1 0 1 1 xxD3
0 0 1 0 1 0 1 1 xxD4
1 0 1 0 1 0 1 1 xxD5
0 1 1 0 1 0 1 1 xxD6
1 1 1 0 1 0 1 1 xxD7
0 0 0 1 1 0 1 1 xxD8
1 0 0 1 1 0 1 1 xxD9
0 1 0 1 1 0 1 1 xxDA
1 1 0 1 1 0 1 1 xxDB
0 0 1 1 1 0 1 1 xxDC
1 0 1 1 1 0 1 1 xxDD
0 1 1 1 1 0 1 1 xxDE
1 1 1 1 1 0 1 1 xxDF
0 0 0 0 0 1 1 1 xxE0
1 0 0 0 0 1 1 1 xxE1
0 1 0 0 0 1 1 1 xxE2
1 1 0 0 0 1 1 1 xxE3
0 0 1 0 0 1 1 1 xxE4
1 0 1 0 0 1 1 1 xxE5
0 1 1 0 0 1 1 1 xxE6
1 1 1 0 0 1 1 1 xxE7
0 0 0 1 0 1 1 1 xxE8
1 0 0 1 0 1 1 1 xxE9
0 1 0 1 0 1 1 1 xxEA
1 1 0
1 0 1 1 1 x
xEB
0 0 1 1 0 1 1 1 xxEC
1 0 1 1 0 1 1 1 xxED
0 1 1 1 0 1 1 1 xxEE
1 1 1 1 0 1 1 1 xxEF
0 0 0 0 1 1 1 1 xxF0
1 0 0 0 1 1 1 1 xxF1
0 1 0 0 1 1 1 1 xxF2
1 1 0 0 1 1 1 1 xxF3
0 0 1 0 1 1 1 1 xxF4
1 0 1 0 1 1 1 1 xxF5
0 1 1 0 1 1 1 1 xxF6
1 1 1 0 1 1 1 1 xxF7
0 0 0 1 1 1 1 1 xxF8
1 0 0 1 1 1 1 1 xxF9
0 1 0 1 1 1 1 1 xxFA
1 1 0 1 1 1 1 1 xxFB
0 0 1 1 1 1 1 1 xxFC
1 0 1 1 1 1 1 1 xxFD
0 1 1 1 1 1 1 1 xxFE
1 1 1 1 1 1 1 1 xxFF
OCH570C
