DISASSEMBLY PROCEDURE
PHOTOS
99
22. How to remove the back panel
(1) Remove the front panel (Refer to Procedure 1).
(2) Remove the side panels (Refer to Procedure 21).
(3)Removethe4screwsonthebackpanel,andremovethe
2screwsthatholdthebackpanelontotheframe.Then
pulloutthebackpanelwhileliftingthetoppanel.(Photos
22-1 and 22-2)
Note:
Thehandlesareremovedbypushingthemup.
Photo 22-1
Handles
Top panel
Screws
(Back panel)
Screws(Toppanel)
Photo 22-2
Top panel
Screw
Back panel
Thephotoshowstheleftside.
Theoppositesidealsohasthescrewtobe
removed on the same position.
Screw(oppositeside)
OCH570C
