Mitsubishi F5MR1 User Manual

MANUAL TRANSMISSION (E-W) -
Transmission
22A-3-2
PWEE9508
E
May 1995Mitsubishi Motors Corporation
25 Nm
39
33
34
32
35
36
40
26
30
37
38
43
31
44
46
29
28
41
42
27
45
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
26. Bolt
A
H
""
Q
A
27. Transmission case
A
H
""
Q
A
28. Poppet spring
A
H
""
Q
A
29. Poppet ball
A
I
""
P
A
30. Magnet
A
I
""
N
A
31. 5th gear shift rail assembly
A
J
""
J
A
32. Spring pin
A
J
""
J
A
33. 1st and 2nd shift rail assembly
A
K
""
K
A
34. Reverse idler gear shaft
A
L
""
J
A
35. Spring pin
A
L
""
H
A
36. 3rd and 4th shift rail assembly
A
L
""
H
A
37. Output shaft
A
L
""
H
A
38. Input shaft
A
N
""
F
A
39. Interlock plungers
A
O
""
E
A
40. Plastic cover
A
P
""
D
A
41. Breather unit
A
P
""
D
A
42. Breather hose
A
Q
""
C
A
43. Oil guide
A
R
""
A
A
44. Output shaft rear bearing
A
R
""
A
A
45. Input shaft rear bearing
A
R
""
A
A
46. Snap ring
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
