MANUAL TRANSMISSION (E-W) -
Transmission
22A-3-2a
PWEE9508
E
May 1995Mitsubishi Motors Corporation
DISASSEMBLY AND REASSEMBLY <F5MR3>
Lubricate all internal
parts with gear oil
during reassembly.
80 Nm
135 Nm
25 Nm
22 Nm
38 Nm
24 Nm
22
2
3
23
24
25
4
5
1
6
7
12
8
13
16
17
18
19
20
21
10
9
15
14
11
22 Nm
RMT0002
Disassembly steps
"
Z
A
1. Backup lamp switch
2. Drain plug
3. Gasket
4. Filler plug
5. Gasket
A
A
""
Y
A
6. Bolt
A
A
""
Y
A
7. Rear cover
A
A
""
Y
A
8. O-ring
A
B
""
W
A
9. Bolt
A
B
""
W
A
10. Shim
A
B
""
W
A
11. Lock nut
A
C
""
X
A
12. Spring pin
A
C
""
V
A
13. 5th speed shift fork
A
C
""
V
A
14. Synchronizer sleeve
A
D
""
V
A
15. Synchronizer spring
A
D
""
V
A
16. Synchronizer hub
A
D
""
T
A
17. Synchronizer ring
A
D
""
T
A
18. 5th speed gear
A
D
""
T
A
19. Bearing sleeve
A
D
""
T
A
20. Retaining ring
A
E
""
U
A
21. 5th gear wheel
A
F
""
S
A
22. Locating pin
A
G
""
R
A
23. Cover plate
A
G
""
R
A
24. Poppet spring
A
G
""
R
A
25. Poppet ball
AddedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
