Mitsubishi F5MR1 - Page 19

MANUAL TRANSMISSION (E-W) -
Transmission
22A-3-7
PWEE9508
E
May 1995Mitsubishi Motors Corporation
A
N
"
INTERLOCK PLUNGERS REMOVAL
Remove the three interlock plungers and the small interlock
plunger from the 1st and 2nd gear shift rail assembly.
A
O
"
PLASTIC COVER REMOVAL
Remove t h e plastic cover from the release fork ball a n d socket
joint.
A
P
"
BREATHER UNIT/BREATHER HOSE REMOVAL
Take the breather unit out of the transmission case. Carefully
remove the breather hose.
A
Q
"
OIL GUIDE REMOVAL
Push in the lug 11 and withdraw the oil guide from the
transmission case.
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
<F5MR1, F5MR2>
<F5MR3>
RMT0010
11
