MANUAL TRANSMISSION (E-W) -
Differential
22A-5-2
PWEE9508
E
May 1995Mitsubishi Motors Corporation
DISASSEMBLY AND REASSEMBLY <F5MR3>
3
5
1
7
11
8
13
6
10
9
15
12
14
2
4
RMT0042
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
1. O-ring
A
A
""
H
A
2. Oil seal
A
C
""
F
A
3. Nut
4. Guard ring
A
E
""
D
A
5. Speedometer drive gear
6. Differential case
7. Snap ring
8. Shim
A
F
""
C
A
9. Side gear
10. Spring pin
11. Bushing
12. Shaft
A
G
""
B
A
13. Pinion gear
14. Washer
A
H
""
A
A
15. Side gear
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
