67
DRIVE THE MOTOR
3
Make a start and stop with terminals (External operation)
REMARKS
Pr. 178 STF terminal function selection must be set to "60" (or Pr. 179 STR terminal function selection must be set to "61"). (all are
initial values)
The motor will not rotate...Why?
Check that [EXT] is lit.
[EXT] is valid when Pr. 79 = "0" (initial value) or "2".
Use to lit [EXT].
Check that wiring is correct. Check it again.
Change the frequency (0Hz) of the minimum value of the potentiometer (0V initial value)
Adjust the frequency in calibration parameter C2 Terminal 2 frequency setting bias frequency. ( Refer to Chapter 4 of the
Instruction Manual (Applied)).
To Next Page
