BODY CONSTRUCTION CHARACTERISTICS
BODY CONSTRUCTION
1-18
REAR FLOOR
AB201025
AB
1
2
5
6
7
8
10
12
13
16
17
14
15
9
11
3
4
1. REAR FLOOR PAN
2. SEAT BACK PLATE EXTENSION
3. JACK BRACKET
4. SPARE TIRE BRACKET
5. REAR SEAT BACK REINFORCEMENT
6. TOWING HOOK REINFORCEMENT
7. CROSSMEMBER CENTER SUPPORT
8. REAR FLOOR CROSSMEMBER
9. REAR FLOOR SEAT BELT REINFORCEMENT
10. DIFFERENTIAL / FUEL SUPPORT BRACKET
REAR
11. REAR FLOOR SIDEMEMBER
12. DIFFERENTIAL / FUEL SUPPORT BRACKET
FRONT
13. REAR SEAT CROSSMEMBER
14. SEAT CROSSMEMBER REINFORCEMENT
15. FUEL TANK FRONT REINFORCEMENT
16. REAR FLOOR EXTENSION
17. FRONT FLOOR SIDEMEMBER EXTENSION
