Mitsubishi LANCER EVOLUTION 2003 Body Repair Manual

1-1
GROUP 1
BODY
CONSTRUCTION
CONTENTS
BODY COMPONENTS. . . . . . . . . . . . 1-2
BODY MAIN CROSS-SECTIONAL
VIEWS . . . . . . . . . . . . . . . . . . . . . . . . 1-4
MAINTENANCE, SERVICEABILITY . 1-6
BODY CONSTRUCTION
CHARACTERISTICS . . . . . . . . . . . . . 1-8
FRONT BODY. . . . . . . . . . . . . . . . . . . . . . . 1-8
ROOF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
SIDE BODY. . . . . . . . . . . . . . . . . . . . . . . . . 1-14
REAR BODY. . . . . . . . . . . . . . . . . . . . . . . . 1-16
UNDER BODY. . . . . . . . . . . . . . . . . . . . . . . 1-17
DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
SILENCER APPLICATION
LOCATIONS . . . . . . . . . . . . . . . . . . . . 1-21
LOCATIONS USING URETHANE FOAM
AND FOAM MATERIAL . . . . . . . . . . . 1-22
STIFFENER AND DAMP SHEET
APPLICATION LOCATIONS . . . . . . . 1-24
THEFT PROTECTION . . . . . . . . . . . . 1-25
