TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
BODY DIMENSIONS
2-8
TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
UNDER BODY
M4020005000161
AB201748
AB201754
AB
1
2
3
4
8
9
11
10
6
806
(31.7)
982
(38.7)
750
(29.5)
1,250
(49.2)
713
(28.1)
1,010
(39.8)
714
(28.1)
177
(7.0)
737
(29.0)
1,232
(48.5)
810
(31.9)
544
(21.4)
940
(37.0)
7
5
mm (in)
291
(11.5)
340
(13.4)
340
(13.4)
172
(6.8)
AB201755
AB
1
10
11
2
3
4
5
6
7
8
9
918
(36.1)
1,170
(46.1)
1,463
(57.6)
1,241
(48.9)
873
(34.4)
911
(35.9)
1,225
(48.2)
848
(33.4)
1,028
(40.5)
756
(29.8)
1,649
(64.9)
718
(28.3)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE
SIZE mm (in)
1 Center of under cover
mounting hole
Round8 (0.3)
2 Front sidemember inner
notch
3 Center of crossmember
mounting hole
Round18 (0.7)
4 Center of front floor
sidemember positioning
hole
Round25 (1.0)
5 Tip of center bearing
mounting bolt (left-front
side)
6 Tip of center bearing
mounting bolt (right-front
side)
7 Tip of center bearing
mounting bolt (left-rear
side)
8 Tip of center bearing
mounting bolt (right-rear
side)
9 Center of rear seat
crossmember positioning
hole
Oblong22×38
(0.9×1.5)
10 Center of crossmember
mounting hole
Round14 (0.6)
11 Center of rear floor
sidemember extension
drain hole
Round20 (1.0)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE
SIZE mm (in)
