BODY DIMENSIONS AND MEASUREMENT METHODS
BODY DIMENSIONS
2-3
6. When measuring the suspension mounting arm, or link
mounting position, use the suspension mounting bolt, etc.
(Type B only)
7. The body center points are shown for the purpose of check-
ing the position of the left and right symmetry location.
AB100782
AB
BOLT
MEASIREMENT POINT
