BRAKE MODULATOR (ABS-ECU)
FOUR-WHEEL ANTI-LOCK BRAKE SYSTEM (4ABS)
35B-9
BRAKE MODULATOR (ABS-ECU)
M2351003000144
The ABS-ECU is basically the same as that of the
LANCER except the followings:
DIAGNOSTIC FUNCTIONS
.
DIAGNOSTIC TROUBLE CODE OUTPUT
.
DTC ITEM
11 Open circuit or short-circuit in ABS sensor (FR)
12 Open circuit or short-circuit in ABS sensor (FL)
13 Open circuit or short-circuit in ABS sensor (RR)
14 Open circuit or short-circuit in ABS sensor (RL)
16 Abnormal drop or rise in ABS-ECU power supply voltage
21 ABS sensor (FR) system
22 ABS sensor (FL) system
23 ABS sensor (RR) system
24 ABS sensor (RL) system
32 Longitudinal G-sensor system
41 Solenoid valve (FR) system
42 Solenoid valve (FL) system
43 Solenoid valve (RR) system
44 Solenoid valve (RL) system
51 Valve relay ON problem
52 Valve relay OFF problem
53 Motor relay OFF problem
54 Motor relay ON problem
55 Motor system
63 ABS-ECU abnormality
71 Lateral G-sensor system
81 Steering angular velocity sensor (ST-1) system
82 Steering angular velocity sensor (ST-2) system
83 Steering angular velocity sensor (ST-N) system
