TRIMS
INTERIOR
52A-9
TRIMS
INTERIOR TRIMS
M2520012000098
• The interiors are fully covered by trims.
• The energy absorption rib molding located in the
back side of the front pillar trim and the rear pillar
trim protect head from side impacts and the resin
materials for the trims are unbreakable materials.
• Nonflammable materials are used for the trims.
Also, material codes are indicated, for recycling.
AC209732
ENERGY ABSORPTION RIB
FRONT PILLAR TRIM
(BACK SIDE)
COWL SIDE TRIM
FRONT PILLAR TRIM
FRONT SCUFF PLATE
LOWER CENTER PILLAR TRIM
REAR SCUFF PLATE
UPPER CENTER PILLAR TRIM
REAR PILLAR TRIM
REAR SHELF TRIM
AB
ENERGY
ABSORPTION RIB
REAR PILLAR TRIM
(BACK SIDE)
To Next Page
