Mitsubishi LANCER EVOLUTION 2003

MASTER CYLINDER
SERVICE BRAKES
35A-4
MASTER CYLINDER
M2350001000145
The master cylinder is a tandem-type, with a struc-
ture that emphasizes safety.
BRAKE BOOSTER ASSEMBLY
M2350002000148
A 8 + 9-inch tandem-type brake booster assembly
has been adopted.
AC005372
AE
MASTER CYLINDER BODY
SECONDARY PISTON ASSEMBLY
BRAKE FLUID RESERVOIR
PRIMARY PISTON ASSEMBLY
PISTON RETAINER
AC206215
AC
REAR DIAPHRAGM
FRONT DIAPHRAGM
PUSH ROD
DIAPHRAGM RETURN SPRING
OPERATING ROD
ATMOSPHERIC CHAMBERS
